Module ID 00106 - Introduction to Basic Rigging A common activity at nearly every construction site is the movement of material and equipment from one place to another using various types of lifting gear. The procedures involved in performing this task are known as rigging. Not every worker will participate in rigging operations, but nearly all will be exposed to it at one time or another. This module provides an overview of the various types of rigging equipment, common hitches used during a rigging operation, and the related Emergency Stop hand signal. (7.5 hours) Module ID 38102 - Rigging Practices Rigging is the preparation of a load for movement, as well as preparation of the hardware and other components used to connect the load to a crane. Rigging is associated with all types of cranes, and rigging skills are also required to move and position equipment inside buildings and other areas where cranes are not involved. This module will provide insight into rigging hardware, lifting slings and their proper use, and various types of rigging equipment (15 hours) Module ID 08303 - Standards and Specifications Standards and codes set the stage for the specifics of how pipefitting is conducted.

They indicate what kinds of materials to use, how to identify those materials, and what procedures to follow in using them. Understanding these areas is just as important as knowing how to cut and join pipe, because pipefitters must follow the law as outlined in the codes and standards. When expectations change over the course of a project, it is essential to get agreements in writing before modifications are made. Staying in compliance is achievable with an understanding of common rules, applications, and methods of conducting business. (10 hours) Module ID 08304 - Advanced Pipefitting Math Pipefitters use geometry, trigonometry, and algebra to calculate takeouts, to lay out angled cuts, and to determine the lengths of the sides of figures and offsets. Knowing which formula to use, and at what time, is central to a craftsperson''s success. Pipefitting calculators are specially designed to assist with each of these functions, yet it is still important to know how the manual process for times when equipment is not available. Precise calculations, no matter how they are realized, form the basis for producing a high-quality pipeline.

(25 hours) Module ID 08305 - Motorized Equipment Two Specialized pieces of motorized equipment, including various types of lifts and rigs, are commonly used in pipefitting work. Fall protection measures must be taken prior to starting any job that involves elevation and trained, certified personnel are required for setup and operation at these sites. Each lift presents its own set of safety considerations, but with careful planning, the risks may be managed. (10 hours) Module ID 08306 - Introduction to Aboveground Pipe Installation Installing aboveground pipe calls for careful planning and communication regarding the measurement, calculation, cutting, and assembly tasks involved in creating fully-functional runs. Aboveground lines do not have the advantage of being supported by the earth of a trench, as with buried pipe, and they often have to be raised to avoid obstructions. Because of these two factors, understanding when, where, and how to apply fundamental pipefitting skills becomes more important than ever. (25 hours) Module ID 08307 - Field Routing and Vessel Trim Field routing and vessel trimming require pipefitters to understand more than pipe assembly. Their decisions play a key role in ensuring the safety and overall success of a job.

From initial evaluation of the site and piping run to the selection of the proper erection equipment and vessel trim components, this part of their job requires them to have a thorough understanding of the competencies and skills taught in this module. (15 hours) Module ID 08308 - Pipe Hangers and Supports Pipe hangers and supports must be carefully chosen to coordinate with the pipe they''re designed to support. As with other components of the system, each piece must be installed in a manner reflective of its strengths and limitations, with attention to piping drawings that outline placement of each item. Many installations and maintenance procedures call for special safety considerations, both during the operation and throughout the lifetimes of individual and overall structures. Pipefitters with strong math skills and solid experience in the basics of the craft are ready for these more advanced activities. (25 hours) Module ID 08309 - Testing Piping Systems and Equipment Once a piping system is installed, it must be tested before it''s ready to use. Like many pipefitting activities, testing introduces a number of hazards that must be addressed. Whether performing hy-drostatic, steam blow, or head pressure testing, precautions must be taken to reduce the known risks.

A good visual inspection of the system is likely to identify certain sets of problems before testing is even begun. When conducting a test, the use of a test report is essential to guiding the overall process. Pipefitters who have mastered installations and repairs are ready to learn about procedures and protocols for testing systems and equipment. (20 hours).
