1 Flow Capacity 1 1.1 Introduction 1 1.2 Flow Coefficient Chart and Flow Curve 8 1.3 Rangeability and Turndown 12 1.4 Valve Authority 14 1.5 Valve Gain 15 Questions and Answers 16 Further Reading 20 2 Valve Sizing 22 2.1 Introduction 22 2.2 Isolation Valve Sizing 22 2.
3 Nonreturn (Check) Valve Sizing 26 2.4 Control Valve Sizing 34 2.4.1 Control Valve Sizing for Liquids 34 2.4.1.1 Specify the Variables Required to Size the Valve 35 2.4.
1.2 Determine the Equation Constant ( N ) 37 2.4.1.3 Determine Piping Geometry Factor ( F P) 37 2.4.1.4 Determine the Maximum Flow Rate ( q max) and Maximum Pressure Drop (Î P max) 39 2.
4.1.5 Solve for Flow Coefficient 44 2.4.1.6 Select the Correct Valve Size 44 2.4.2 Control Valve Sizing for Gas and Steam 47 2.
4.2.1 Specify the Variables Required to Size the Valve 47 2.4.2.2 Determine the Equation Constant ( N ) 48 2.4.2.
3 Determine Piping Geometry Factor ( F P) 48 2.4.2.4 Determine the Expansion Factor ( Y ) 48 2.4.2.5 Solve for the Required Flow Coefficient ( C v) 50 2.5 Safety Relief Valve Sizing 56 2.
5.1 Sizing for Gas or Vapor Relief 59 2.5.1.1 Critical Flow 59 2.5.1.2 Subcritical Flow 73 2.
5.2 Sizing for Steam Relief 75 2.5.3 Sizing for Liquid Relief 79 2.5.3.1 Sizing for Liquid Relief with Capacity Certification 79 2.5.
3.2 Sizing for Liquid Relief Without Capacity Certification 84 2.5.4 Sizing for Two-Phase Liquid/Vapor Relief 85 2.5.4.1 Sizing for Saturated Liquid and Saturated Vapor, Liquid Flashes 88 2.5.
4.2 Sizing for Subcooled at the Pressure Relief Valve Inlet 91 2.5.5 Sizing for Fire Case and Hydraulic Expansion 93 2.5.5.1 Hydraulic Expansion (Thermal Expansion) 95 2.5.
5.2 Sizing Safety Valve for the Fire Case 96 Questions and Answers 103 Further Reading 110 3 Cavitation and Flashing 112 3.1 Introduction 112 3.2 Cavitation 112 3.2.1 What is Cavitation? 112 3.2.2 Cavitation Essential Parameters 113 3.
2.3 Cavitation Analysis 115 3.3 Flashing 116 Questions and Answers 118 Further Reading 123 4 Wall Thickness 125 4.1 Introduction 125 4.2 ASME B16.34 Minimum Wall Thickness Calculation 125 4.2.1 Conservation Approach (Mandatory Appendix A) 125 4.
2.2 Nonconservation Method 129 4.2.3 ASME Sec. VIII Div. 02 Wall Thickness Calculation 134 4.3 Wafer Design Thickness Validation 136 Questions and Answers 142 Further Reading 147 5 Material and Corrosion 149 5.1 Introduction 149 5.
2 Carbon Dioxide Corrosion 150 5.2.1 Corrosion Mechanism 150 5.2.2 Corrosion Mitigation 151 5.2.3 Corrosion Rate Calculation 152 5.2.
3.1 Basic CO2 Corrosion Rate 152 5.2.3.2 Corrective CO2 Corrosion Rate 154 5.2.3.3 Final CO2 Corrosion Rate 161 5.
3 Pitting Corrosion 162 5.4 Carbon Equivalent 165 5.5 Hydrogen-Induced Stress Cracking (HISC) Corrosion 167 5.5.1 HISC and Vulnerable Materials 168 5.5.2 HISC and Stress 168 5.5.
3 HISC and Cathodic Protection 168 5.5.4 HISC and DNV Standard 169 Questions and Answers 177 Further Reading 184 6 Noise 185 6.1 Introduction to Sound 185 6.2 Introduction to Noise 186 6.3 Noise in Industrial Valves 189 6.3.1 Mechanical Noise and Vibration 190 6.
3.2 Fluid Noise 190 6.3.2.1 Aerodynamic Noise 191 6.3.2.2 Hydrodynamic Noise 191 6.
3.3 Noise Control Strategies 191 6.4 Noise Calculations for Pipes and Valves 192 6.4.1 Acoustic Fatigue Analysis 192 6.4.1.1 Sound Power Level Calculations 193 6.
4.1.2 Mach Number 198 6.4.2 Noise in Control Valves 203 6.4.2.1 Aerodynamic Noise in Control Valves 203 6.
4.2.2 Hydrodynamic Noise in Control Valves 208 6.4.3 Noise in Pressure Safety or Relief Valves 215 6.4.3.1 Calculation of Noise Emission According to ISO 4126-9 216 6.
4.3.2 Calculation of Noise Emission According to API 521 218 6.4.3.3 Calculation of Noise Emission According to VDI 2713 221 Questions and Answers 222 Further Reading 231 7 Water Hammering 233 7.1 Introduction 233 7.2 Water Hammering and Pressure Loss in Check Valves 233 7.
3 Water Hammering Calculations 243 Questions and Answers 249 Further Reading 256 8 Safety Valves 258 8.1 Introduction 258 8.2 Safety Valve Parts 259 8.3 Safety Valve Design and Operation 259 8.3.1 Design and Operation Parameters 259 8.3.1.
1 Overpressure Criteria 277 8.3.2 Principle of Operation 278 8.3.3 Safety Valve Reaction Forces 282 8.3.4 Safety Valve Capacity Conversion 294 Questions and Answers 296 Further Reading 302 9 Safety and Reliability 304 9.1 Introduction 304 9.
2 Safety Standards 305 9.3 Risk Analysis 308 9.4 Basic Safety and Reliability Concepts 312 9.4.1 System Incidents and Failures 312 9.4.1.1 Failure Rate 313 9.
4.1.2 Repair Rate 317 9.4.1.3 Mean Time to Failure (MTTF) 317 9.4.1.
4 Mean Time Between Failure (MTBF) 318 9.4.1.5 Mean Time to Repair and Recovery (MTTR) 319 9.4.1.6 Mean Time to Detection (MTTD) 319 9.4.
2 Reliability and Unreliability 319 9.4.3 Availability and Unavailability 331 9.5 Safety Integrity Level (SIL) Calculations 336 9.5.1 SIL 336 9.5.2 Probability of Failure on Demand (PFD) 338 9.
5.3 Mean Downtime 339 9.5.4 Diagnostic Coverage 342 9.5.5 Safe Failure Fraction (SFF) 342 9.6 Condition Monitoring (ValveWatch) 347 Questions and Answers 348 Further Reading 354 10 Valve Operation 357 10.1 Introduction 357 10.
2 Valve Torque 358 10.3 Stem Design 363 10.3.1 MAST Calculations 363 10.3.2 Buckling Prevention 369 10.3.3 Torsional Deflection Prevention 374 10.
3.4 MAST Limitation for Quarter-Turn Cryogenic Valves 376 Questions and Answers 378 Further Reading 384 11 Miscellaneous 385 11.1 Introduction 385 11.2 Joint Efficiency 386 11.2.1 Weld Joint Efficiency 386 11.2.2 Bolted Joint Efficiency 388 11.
2.2.1 Bolted Bonnet or Cover Joints 388 11.2.2.2 Bolted Body Joints 392 11.2.3 Threaded Joint Efficiency 394 11.
2.3.1 Threaded Bonnet or Cover Joints 394 11.2.3.2 Threaded Body Joints 395 11.3 Stem Sealing 395 Questions and Answers 399 Further Reading 405 Index 407.
