FSM-Based Digital Design Using Verilog HDL
FSM-Based Digital Design Using Verilog HDL
Click to enlarge
Author(s): Minns, Peter D.
ISBN No.: 9780470987629
Pages: 408
Year: 200804
Format: E-Book
Price: $ 253.85
Dispatch delay: Dispatched between 7 to 15 days
Status: Available

CHAPTER 1 - THE BASICS Introduction What is a Finite State Machine Number of States Number required for State Diagram - Frame 1.3 Mealy FSM Moore FSM Class C FSM Introduction to the State Diagram - States, Transitions & Inputs Input Signals - Frames 1.8 to 1.9, Output Signals - Frame 1.9 Inputs and Outputs of FSM Inverted Inputs - Frame 1.11 Active High Signals - Frames 1.11 Assignment - Frame 1.11 Non-Unit Distance Coding - Frame 1.


11 Secondary State Variables Unit Distance Coding - Frame 1.12 to Frame 1.14. Active Low Signals - Frame 1.14 Mealy Outputs - Frame 1.16, 1.19, 1.20, 1.


21, from Effect of clock on Mealy output signals Summary - Frame 1.22 CHAPTER 2 - CONTROLLING OUTSIDE WORLD DEVICES Introduction Using Timer to Introduce Wait States - Frame 2.1 to 2.3 Analogue to Digital Converters - Frame 2.4 Data Acquisition System - Frame 2.4, Frame 2.9 & Frame 2.10 from Memory: How to Control in FSM''s - Frame 2.


5 to 2.10 Chip Select & Read and Write Sequences Frames 2.5 to 2.7 - (See also Chapter 4, Section 4.4, Chapter 5, Sections 5.2, 5.3, 5.4, 5.


6, 5.8.) Monitoring Inputs for Changes - Frame 2.11 to 2.14 Dealing with Incorrect Input States - Frame 2.14 Summary CHAPTER 3 - SYNTHESISING FSMS Introduction Synthesising using T Type Flip Flops - Frame 3.1 to 3.7 T Type Flip Flop T Flip Flop Example in a State Diagram Developing T Flip Flop Equations from the State Diagram Examples of Developing T Equations from a Number of State Diagrams Solutions to the Examples D Type Flip Flops Developing D Flip Flop Equations from a State Diagram Rule 1: Dealing with 1 to 0 with Input Terms Rule 2: Dealing with 1 to 1 Transitions Rule 3: Dealing with two-way Branches Using the Two-way Branch Rule Examples of Obtaining D Flip Flop Equations from a State Diagram State Diagram with Two-way Branch States: Obtaining D Type Equations Resetting the Flip Flop Examples of Developing D Equations from a Number of State Diagrams Solutions to the Examples Asynchronous and Synchronous Resetting of Flip Flops Complete Design of Circuit for a Particular Design Dealing with Multi-way Branch States using D Type Flip Flops Dealing with Active Low Output Signals in an FSM Dealing with Active Low Mealy Output Signals in an FSM Summary CHAPTER 4 - SYNCHRONOUS FSM DESIGNS 4.


1 Traditional FSM Design Method Verses Method used in this Book 4.2 Dealing with Unused States 4.3 High/Low Alarm Indicator System 4.4 Simple Waveform Generator 4.5 Dice Game 4.6 Binary Data Serial Transmitter 4.7 Development of a Serial Asynchronous Receiver 4.8 Adding Parity Detection to the Serial Receiver System 4.


9 Asynchronous Serial Transmitter System 4.10 Clocked Watchdog Timer 4.11 Summary CHAPTER 5 -ONE HOT DESIGNS 5.1 One Hot Technique of FSM Design 5.2 Data Acquisition System (DAS) 5.3 A Shared Memory System 5.4 Fast Waveform Synthesiser 5.5 Controlling the FSM from a Microprocessor 5.


6 Memory Chip Tester 5.7 Comparing One Hot Solution with more Conventional Design Method of Chapter 4 5.8 Dynamic Memory Access (DMA) Controller 5.9 How to Control the DMA Controller from a Microprocessor 5.10 Detecting Binary Sequences using an FSM 5.11 Summary CHAPTER 6 - INTRODUCTION TO VERILOG-HDL A Brief Background to HDLs Hardware Modelling with Verilog-HDL - the Module Modules within Modules : Creating Hierarchy Verilog-HDL Simulation : A Complete Example References and Further Reading CHAPTER 7 - ELEMENTS OF VERILOG-HDL Built-in Primitives and Types 7.1.1 Verilog Types 7.


1.2 Verilog Logic and Numeric Values 7.1.3 Specifying Values 7.1.4 Verilog-HDL Primitive Gates Operators and Expressions Example Illustrating the use of Verilog-HDL Operators - Hamming Code Encoder References and Further Reading CHAPTER 8 - DESCRIBING COMBINATIONAL AND SEQUENTIAL LOGIC USING VERILOG=HDL The Data Flow Style of Description - Review of the Continuous Assignment The Behavioural Style of Description - The Sequential Block Assignments within Sequential Blocks : Blocking and Non-Blocking Describing Combinational Logic using a Sequential Block Describing Sequential Logic using a Sequential Block Describing Memories Describing Finite State Machines: Example 1 Chess Clock Controller FSM Example 2 Combinational Lock FSM with Automatic Lock Feature References and Further Reading CHAPTER 9 - ASYNCHRONOUS FSM DESIGN 9.1 Introduction 9.2 Development of Event Driven Logic 9.


3 Using the Sequential Equations to Synthesise an Event FSM 9.3.1 Short Cut Rule 9.4 Implementing the Design using Sum of Product as PLD 9.5 Development of an Event Version of the Single Pulse Generator with Memory FSM 9.6 Another event FSM design through to simulation 9.7 The Hover Mower FSM 9.8 An Example with a Transition Without any Input 9.


9 Unusual Example responding to a Microprocessor Address Location 9.10 Example that uses a Mealy Output 9.11 Example using a Relay Circuit 9.12 Race Conditions in Event FSMs 9.13 Wait State Generator for a Microprocessor System 9.14 Development of an Asynchronous FSM to Control a Clothes Spin System 9.15 Summary CHAPTER 10 - PETRI-NETS 10.1 Introduction to Simple Petri-Nets 10.


2 Sequential Petri-Net Example, the Pump Spin Motor Problem 10.3 Parallel Petri-Nets 10.4 Synchronising Flow in a Parallel Petri-Net 10.5 Using Enabling/Disabling Arcs to Synchronise Flow between Two Petri-Nets 10.6 Example - Control of Shared Resource 10.7 A Serial Receiver of Binary Data using a Petri-Net Controller 10.8 Summary APPENDIX INDEX APPENDIX A1 - LOGIC GATES AND BOOLEAN ALGEBRA IN THE BOOK Introduction A1.1 Basic Gate Symbols used in the Book A1.


2 Exclusive OR and Exclusive NOR Symbols A1.3 Laws of Boolean Algebra: A1.3.1 Basic OR Rules A1.3.2 Basic AND Rules A1.3.3 Associative Laws and Commutative Laws A1.


3.4 Distributive Laws A1.3.5 Auxiliary Law - For Static 1 Hazard Removal A1.3.5.1 Proof of the Auxiliary Law A1.3.


6 The Consensus Theorem A1.3.7 Effect of Signal Delay on Logic Gates A1.3.8 De-Morgans Theorem A1.4 Examples of Applying the Laws of Boolean Algebra A1.4.1 Converting AND-OR to NAND A1.


4.2 Converting AND-OR to NOR A1.4.3 Logical Adjacency Rule A1.5 Summary APPENDIX A2 - COUNTING & SHIFTING CIRCUIT TECHNIQUES Introduction A2.1 Basic Up Down Synchronous Binary Counter Development A2.2 Example of a Four Bit Synchronous up Counter using T Flip Flops A2.3 Parallel Loading Counters A2.


4 Using D Flip Flops to Build Parallel Loading Counters A2.5 Simple Binary Up Counter A2.6 Clock Circuit to Drive the Counter (and FSMs) A2.7 Counter Design using Don''t Cares A2.8 Shift Registers A2.9 Asynchronous Receiver Details for Section 4.7 Chapter 4 A2.9.


1 Eleven Bit Shift Register for the Asynchronous Receiver Module A2.9.2 Divide by Eleven Counter A2.9.3 Complete Simulation of the Asynchronous Receiver System A2.10 Summary APPENDIX A3 - TUTORIAL ON THE USE OF VERILOG HDL TO SIMULATE AN FSM DESIGN A3.1 Introduction A3.2 Single Pulse with Memory Synchronous FSM Design A3.


2.1 Specification A3.2.2 Block Diagram A3.2.3 State Diagram A3.2.4 Equations from the State Diagram A3.


2.5 Translation into a Verilog Description A3.3 Test Bench Module and its Purpose A3.4 Using the Verilogger Simulator A3.4.1 Output from the Simulator A3.5 Summary APPENDIX A4 - IMPLEMENTING STATE MACHINES USING VERILOG BEHAVIOURAL MODE A4.1 Introduction A4.


2 Example 1- The Single Pulse with Memory FSM Revisited A4.3 The Memory Tester in Chapter 5, Section 5.6 Revisited A4.4 Summary.
