INTRODUCTION Description, Analysis and Transformation: Drawing as Diagram CHAPTER 1: CONVENTIONS 1 Point, Line, Plane and Volume 2 Plan Conventions 2.1 Orthographic Projections (Elevation) 2.2 Cut-away Views (Plan and Section) 2.3 Paraline Drawings 2.4 Perspective Drawings 3 Graphic Conventions 3.1 Line Weight, Style and Type 3.2 Hatching, Texture, Material and Shading 3.3 Colour 3.
4 Drawing Scale and Paper Size 3.5 Annotation and Dimensioning CHAPTER 2: ARCHITECTURE 1 Description 1.1 Context: Location Plan and Site Section 1.2 Building: Plan, Elevation and Section 1.3 Building: Axonometric and Perspective 2 Analysis 2.1 Context: Figure-Ground Plan 2.2 Context: Orientation 2.3 Building: Massing 2.
4 Building: Structural Organisation 2.5 Building: Programme 2.6 Building: Circulation-to-Use 2.7 Building: Part-to-Whole 2.8 Building: Repetitive-to-Unique 2.9 Building: Geometrical Order 2.10 Building: Parti 3 Comparison 3.1 Free Plan vs Raumplan 3.
2 Deconstruction of Whole to Parts 3.3 Vertical vs Horizontal 3.4 Sectional Organisation 3.5 Landscape and Landform 3.6 Modularity 4 Comparative Matrices 4.1 Massing 4.2 Conceptual Organisation 4.3 Disposition 4.
4 Distribution 4.5 Circulation 4.6 Difference 4.7 Growth CHAPTER 3: THE URBAN 1 Description 1.1 Urban Plan 1.2 Land Use 1.3 Density 1.4 Circulation (Transport) 1.
5 Open Spaces 1.6 Infrastructures 2 Analysis 2.1 Figure-Ground Plan 2.2 Hierarchies and Organisation 2.3 Part-to-Whole and Repetitive-to-Unique 2.4 Built Environment 2.5 Phasing 3 Comparison 3.1 Block 3.
2 Enclave 3.3 Ground 3.4 Infrastructure 4 Comparative Matrices 4.1 Size 4.2 Distribution 4.3 Hierarchy and Layering 4.4 Difference 4.5 Growth 4.
6 Architectural Types and Urban Morphology CHAPTER 4: TRANSFORMATION 1 Typological Transformation 1.1 Timeline 1.2 Comparative Matrix 1.3 Comparative Diagrams 1.4 Typological Transformation Diagrams 1.5 Transformative Matrix 2 Design Examples 2.1 Tokyo Podium by Sakiko Goto 2.2 The City Campus by Marcin Ganczarski 2.
3 The Chinese Unit by Yuwei Wang 2.4 Cité Housing by Alvaro Arancibia Tagle Drawing Acknowledgements and References.
